Introduction to OTA Measurement for mmWave and Sub-THz with MilliBox and CMT Components

Jeanmarc Laurent from MilliBox is showing a live demo of an accessible complete OTA system setup consisting of a VNA, an anechoic chamber and a 3D DUT positioner.

During this course we will cover the following points:


  • How to select the right positioner type
  • How to select the right chamber size
  • How to operate the MilliBox software controller
  • How to collect and process the data from a VNA
  • How to expend this setup for frequency beyond 50GHz
  • Q&A
